FTIR

The GT5000 Terra is a compact, lightweight, and IP54-rated (splashproof) portable FTIR gas analyzer, delivering laboratory-grade accuracy in the field. Designed for professionals across various industries, such as research and occupational safety, it provides precise, real-time multi-gas analysis in demanding conditions. If you're looking for the best portable ftir gas analyzer, look no further.

The Gasmet Continuous Emission Monitoring System CEMS II e offers a TÜV/MCERTS-certified solution (QAL1) for a wide range of applications in the field of process and emission monitoring. Since all components are heated to 180°C, this extractive system is ideal for measuring gas components from hot, wet and corrosive gas streams.

A typical application is the simultaneous measurement of the following 16 gases to assess the emissions of an incinerator: H2O, CO2, CO, N2O, NO,NO 2, SO2, HCl, HF, NH3, CH4, C2H6, C3H8, C6H14, C2H4 and CH2O.

The CEMS II e is a modular system, usually consisting of the Gasmet CX4000 FTIR gas analyzer, a heated sampling unit with sampling probe, pump and filters, and an industrial PC with Calcmet software. If required, the CEMS II e can be equipped with a oxygen analyzer and/or a flame ionization detector GFID.

The Gasmet DX4015 is a portable FTIR gas analyzer for ambient air analysis in humid conditions, as it has a sample cell heating up to 50°C.

The main features of the Gasmet DX4015 are a high-sensitivity measuring cell for the lowest detection limits (optical path length 980 cm) and a built-in pump, so that no separate sampling system is needed. The device can optionally be supplied with 12 VDC via an external battery, so that measurements can be carried out without any problems even under field conditions where no mains voltage is available.

The Gasmet CX4000 is an industrial multi-component gas analyzer for continuous process and emission monitoring. The device is controlled by an external computer, and up to 50 components from ppm to vol.% can be measured simultaneously.

The GT6000 Mobilis is an EN15267-4 QAL1-certified (MCERTS) FTIR portable emissions gas analyzer for accurate, reliable, and fast multi-gas measurements in the field. Whether you're conducting stack testing, on-site emissions monitoring, or combustion research, it delivers certified, lab-grade analysis without compromise.

The gas analyzer is typically set up to measure H2O, CO2, CO, NO, NO2, N2O, SO2, NH3, CH4, HCl, HF and different VOCs and can measure up to 50 gases simultaneously. It is designed to be used with the portable sampling system, PSS Plus or PSS Base. PSS utilizes the hot-and-wet measurement principle (no drying or dilution).

The GT7000 Tellus is a next-generation rack-mountable FTIR gas analyzer built for integration into multi-instrument measurement systems. It can measure simultaneously up to 50 gases, providing instant gas concentration results with complex gas mixture analysis. The analyzer operates at 180°C or 50°C, with heated sample cell for wet and corrosive gases.
